CP Bullet LT1 Pistons (2014-16)
Part#: BLT-1000-STD / Bore: 4.065 / Stroke: 3.622 / Rod: 6.125 / Comp Height: 1.300 / C/R: 11.9:1 / No Pin Upgrade
$1,915.00
Skip to product information
CP Bullet LT1 Pistons (2014-16)
$1,915.00
CP Bullet Series Pistons
Suit Chevrolet LT1 (2014-2016)
| Part Number | Bore | Stroke | Rod | Comp Height | Head Type | Head CC | Dome Height | Dish / Dome | C/R | Pin Dia | VR Depths | Weight | Type | VR |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BLT-1000-STD | 4.065 | 3.622 | 6.125 | 1.300 | LT1 14-16 | 58.2 | Dome | +.6cc | 11.9:1 | .927 x 2.250 | .180/ .200 | TBD | Dome | 2 VR's |
| BLT-1001-005 | 4.070 | 3.622 | 6.125 | 1.300 | LT1 14-16 | 58.2 | Dome | +.6cc | 11.9:1 | .927 x 2.250 | .180/ .200 | TBD | Dome | 2 VR's |
| BLT-1002-STD | 4.065 | 3.622 | 6.125 | 1.300 | LT1 14-16 | 58.2 | Dome | -10.7cc | 10.5:1 | .927 x 2.250 | .205/ .200 | 535 | Dish | 2 VR's |
| BLT-1006-005 | 4.070 | 4.000 | 6.125 | 1.115 | LT1 14-16 | 58.2 | Dish | -10cc | 11.7:1 | .927 x 2.250 | .180/ .200 | TBD | Dish | 2 VR's |
| BLT-1007-005 | 4.070 | 4.000 | 6.125 | 1.115 | LT1 14-16 | 58.2 | Dish | -20cc | 10.5:1 | .927 x 2.250 | .180/ .200 | TBD | Dish | 2 VR's |
Features Included:
- Pistons manufactured from 2618 alloy for strength and durability
- Balanced to + or – 1 gram
- Dual forced pin oilers
- Contact reduction grooves
- Accumulator Grooves
- Contemporary ring set included (Comes standard with 1.5mm x 1.5mm x 3.0mm ring pack that consists of High-grade Steel Gas Nitrided barrel faced tops with Taper Hook Groove Napier second rings and a 3-piece soft nitrided rail flex vent oils, specially designed for severe duty applications such as nitrous blowers and turbo engines.)
- Forged side relief
- Chromoly wrist pins with wire locks
- FEA designed forging
- Tight tolerances
- USA made
Available options
- Piston Options: Part#: BLT-1000-STD / Bore: 4.065 / Stroke: 3.622 / Rod: 6.125 / Comp Height: 1.300 / C/R: 11.9:1; Part#: BLT-1001-005 / Bore: 4.070 / Stroke: 3.622 / Rod: 6.125 / Comp Height: 1.300 / C/R: 11.9:1; Part#: BLT-1002-STD / Bore: 4.065 / Stroke: 3.622 / Rod: 6.125 / Comp Height: 1.300 / C/R: 10.5:1; Part#: BLT-1006-005 / Bore: 4.070 / Stroke: 4.000 / Rod: 6.125 / Comp Height: 1.115 / C/R: 11.7:1; Part#: BLT-1007-005 / Bore: 4.070 / Stroke: 4.000 / Rod: 6.125 / Comp Height: 1.115 / C/R: 10.5:1
- Pin Upgrades: No Pin Upgrade; 0.200" 9310 Pins; 0.240" 9310 Pins
Engine build fitment
Chev LT1. Match the selected dimensions, engine generation and rotating assembly specification before machining or assembly.
Installation and BBT workshop support
Confirm finished bore size, piston-to-wall clearance, compression height, pin specification, ring gaps and valve clearance against the supplied piston documentation.
Built by Boost & Tune is an authorised Spool Imports dealer and can assist with component selection, engine assembly and tuning requirements for your build.
