CP Pistons EVO VIII / EVO IX — product detail 1

CP Pistons EVO VIII / EVO IX

Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7232
$1,240.00
Skip to product information
CP Pistons EVO VIII / EVO IX — product detail 1
  • CP Pistons EVO VIII / EVO IX — product detail 1
  • CP Pistons EVO VIII / EVO IX — product detail 2
  • CP Pistons EVO VIII / EVO IX — product detail 3
CP Pistons EVO VIII / EVO IX

CP Pistons EVO VIII / EVO IX

$1,240.00

CP Pistons for EVO VIII / EVO IX Engines

Available in:

88mm Stroke

  • Bore: 85mm (STD) / Stroke: 88mm / Comp: 9.0:1 - Part#: SC7228
  • Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 9.0:1 - Part#: SC7229
  • Bore: 86mm (+1mm) / Stroke: 88mm / Comp: 9.0:1 - Part#: SC7230
  • Bore: 85mm (STD) / Stroke: 88mm / Comp: 9.5:1 - Part#: SC7199
  • Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 9.5:1 - Part#: SC7201
  • Bore: 86mm (+1mm) / Stroke: 88mm / Comp: 9.5:1 - Part#: SC7203
  • Bore: 85mm (STD) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7231
  • Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7232
  • Bore: 86mm (+1mm) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7233

94mm Stroke

  • Bore: 85mm (STD) / Stroke: 94mm / Comp: 9.5:1 - Part#: SC7215
  • Bore: 85.5mm (+0.5mm) / Stroke: 94mm / Comp: 9.5:1 - Part#: SC7216
  • Bore: 86mm (+1mm) / Stroke: 94mm / Comp: 9.5:1 - Part#: SC7217

100mm Stroke

  • Bore: 85mm (STD) / Stroke: 100mm / Comp: 9.0:1 - Part#: SC7252
  • Bore: 85.5mm (+0.5mm) / Stroke: 100mm / Comp: 9.0:1 - Part#: SC753
  • Bore: 86mm (+1mm) / Stroke: 100mm / Comp: 9.0:1 - Part#: SC7254
  • Bore: 85mm (STD) / Stroke: 100mm / Comp: 9.5:1 - Part#: SC7197
  • Bore: 86mm (+0.030mm) / Stroke: 100mm / Comp: 9.5:1 - Part#: SC7208
  • Bore: 85.5mm (+0.5mm) / Stroke: 100mm / Comp: 9.5:1 - Part#: SC7206
  • Bore: 85mm (STD) / Stroke: 100mm / Comp: 10.1:1 - Part#: SC7255
  • Bore: 85.5mm (+0.5mm) / Stroke: 100mm / Comp: 10.1:1 - Part#: SC7256
  • Bore: 86mm (+1mm) / Stroke: 100mm / Comp: 10.1:1 - Part#: SC7257

Available options

  • Piston Options: Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7232; Bore: 85mm (STD) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7231; Bore: 86mm (+1mm) / Stroke: 88mm / Comp: 10.5:1 - Part#: SC7233; Bore: 85mm (STD) / Stroke: 88mm / Comp: 9.0:1 - Part#: SC7228; Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 9.0:1 - Part#: SC7229; Bore: 86mm (+1mm) / Stroke: 88mm / Comp: 9.0:1 - Part#: SC7230; Bore: 85mm (STD) / Stroke: 88mm / Comp: 9.5:1 - Part#: SC7199; Bore: 85.5mm (+0.5mm) / Stroke: 88mm / Comp: 9.5:1 - Part#: SC7201; Bore: 86mm (+1mm) / Stroke: 88mm / Comp: 9.5:1 - Part#: SC7203; Bore: 85mm (STD) / Stroke: 94mm / Comp: 9.5:1 - Part#: SC7215; Bore: 85.5mm (+0.5mm) / Stroke: 94mm / Comp: 9.5:1 - Part#: SC7216; Bore: 86mm (+1mm) / Stroke: 94mm / Comp: 9.5:1 - Part#: SC7217; Bore: 85mm (STD) / Stroke: 100mm / Comp: 9.0:1 - Part#: SC7252; Bore: 85.5mm (+0.5mm) / Stroke: 100mm / Comp: 9.0:1 - Part#: SC7253; Bore: 86mm (+1mm) / Stroke: 100mm / Comp: 9.0:1 - Part#: SC7254; Bore: 85mm (STD) / Stroke: 100mm / Comp: 9.5:1 - Part#: SC7197; Bore: 86mm (+0.030mm) / Stroke: 100mm / Comp: 9.5:1 - Part#: SC7208; Bore: 85.5mm (+0.5mm) / Stroke: 100mm / Comp: 9.5:1 - Part#: SC7206; Bore: 85mm (STD) / Stroke: 100mm / Comp: 10.1:1 - Part#: SC7255; Bore: 85.5mm (+0.5mm) / Stroke: 100mm / Comp: 10.1:1 - Part#: SC7256; Bore: 86mm (+1mm) / Stroke: 100mm / Comp: 10.1:1 - Part#: SC7257

Engine build fitment

EVO VIII / EVO IX. Match the selected dimensions, engine generation and rotating assembly specification before machining or assembly.

Installation and BBT workshop support

Confirm finished bore size, piston-to-wall clearance, compression height, pin specification, ring gaps and valve clearance against the supplied piston documentation.

Built by Boost & Tune is an authorised Spool Imports dealer and can assist with component selection, engine assembly and tuning requirements for your build.
Shop more Mitsubishi 4G63 parts
