Harrop Camshaft H05 | GM LS V8

Harrop H05 Camshaft | GM LS V8

Harrop H05 is an entry-level supercharger grind with a wider lobe separation angle, also suited to naturally aspirated LS combinations where a relatively smooth idle is preferred.

Harrop H05 specifications

• Duration: 216° intake / 224° exhaust
• Valve lift: 0.593" intake / 0.592" exhaust
• Lobe separation angle: 116°
• Product code: 65-LSCAM-H05

Application guidance

Harrop states that the H05 can work well with standard torque-converter and differential ratios, making it a lower-supporting-modification cam choice than the more aggressive grinds.

Fitment

Holden Commodore VT–VF models including HSV variants fitted with compatible GM LS-series engines.
