BA/F PSR3582 Gen 2 Dual Ball Bearing Turbocharger External Wastegate Version

BA/F PSR3582 Gen 2 Dual Ball Bearing Turbocharger External Wastegate Version from Pulsar Turbo Systems Australia. Select the exact configuration and view its corresponding price before adding to cart.

• New Aerodynamic 10 blade billet compressor wheel flow more air over the stock cast or Gen1 11 blade billet wheel
• New Aerodynamic 9 blade turbine wheel, less weight, lower inertia, and higher flowability
• Genuine structure and rebuildable dual ceramic ball bearing system
• Larger 0.72A/R compressor cover with Anti-Surge 4″ inlet
• Billet actuator with black anodized coating
• 3 Layer Stainless Steel 5 Bolt Gasket
• Compressor Wheel: 65.7*82.6mm(extended tip diameter: 85.29mm)
• Turbine Wheel: 68*62.3mm
• Compressor Inlet: 4″ Hose
• Compressor Outlet: 2.5″ Hose
• Turbine Inlet: T3 Open
• Turbine Outlet: 5 Bolt
• Turbine housing internal wastegate hole: 33mm
• Water Ports: -6AN
• Oil Feed: -4AN to the Oil Restrictor
• Oil Drain: Std T3 Oil Drain Flange
• Suits all BA and BF Falcons
• Comes as a Complete Turbo
• Suits PSR New Generation 45mm Wastegate or Turbosmart Gen V Wastegate

Choose the external wastegate configuration

Select the compressor cover and optional 45 mm wastegate for the listed Falcon generation. The displayed total price follows the selected variant. Confirm the exhaust manifold, outlet connection and available engine-bay clearance before ordering.

Current selectable options

• Compressor Housing Option: Standard, T51R
• Add Wastegate: No, PSR New Generation 45mm Black, PSR New Generation 45mm Silver, Turbosmart Gen V 45mm Red, Turbosmart Gen V 45mm Black, Turbosmart Gen V 45mm Blue
