Name: Crow Cams Ford FG 315 kW Exhaust Beehive Valve Springs — 16 Pack
Brand: Crow Cams
SKU: 1809-16
Price: 349.52 AUD
Availability: InStock

Crow Cams Ford FG 315 kW Exhaust Beehive Valve Springs — 16 Pack

$349.52

Crow Cams Ford FG 315 kW Exhaust Beehive Valve Springs — 16 Pack

Set of 16 exhaust beehive valve springs for Ford FG 315 kW modular V8 cylinder heads. Crow specifies a 39.06 mm exhaust installed height.

Supplied contents and matching parts

16 exhaust springs. The matching inlet application uses the separate 1804-16 set at 43 mm installed height. Crow recommends both spring sets with FG3152567, FG3152568 and FG3152569 cam sets.

Supplier spring dimensions

Spring part number	1809
Inside / outside diameter at top	0.650 / 0.980 inch
Inside / outside diameter at bottom	0.730 / 1.070 inch
Coil-bind height	0.880 inch
Listed spring rate	208 lb/in

Installation and BBT support

Have the installer verify cam timing, piston-to-valve clearance, spring pressures, coil-bind clearance and retainer-to-seal clearance on the actual engine. BBT can help select the supporting parts and arrange installation and calibration.

Applications and compatibility

This part is listed for the following engine and vehicle applications where the Crow camshaft or valvetrain package calls for this exact part number:

Ford Falcon FG — Boss 5.4L V8

Compatibility is still determined by the complete cylinder-head and camshaft combination; vehicle model alone is not a substitute for checking the required spring, retainer, lock, lifter and rocker setup.

Installation checks

Measure installed height and verify seat/open pressure, coil-bind margin, retainer-to-seal clearance and guide/seal clearance on the actual cylinder heads. Match the spring to the exact cam profile rather than selecting by engine family alone.

Associated Crow camshaft listings on BBT

This component is called up by Crow on applicable camshaft packages including:

The list above is representative rather than universal. Use the recommendation table on the exact camshaft page or contact BBT with the cam part number before ordering a complete valvetrain package.

Ordering and BBT support

Built by Boost & Tune can help confirm the correct Crow camshaft, springs, retainers, locks, lifters, rockers, timing components and supporting hardware as one compatible package. For modified cylinder heads, non-standard valves or an unknown existing combination, provide the engine specification and measured valvetrain details before ordering.
