Crow Cams BAF260XR82 is a four-camshaft engine set for the Ford Falcon BA/BF Boss 260 kW engine only. Performance profile for the 260 kW engine.
Camshaft specifications
| Supplier part number | BAF260XR82 |
|---|---|
| Application | Ford Falcon BA/BF Boss 260 kW engine only |
| Operating range | 2500–6500 rpm |
| Advertised duration — inlet / exhaust | 254° / 254° |
| Duration at 0.050 inch — inlet / exhaust | 202° / 202° |
| Valve lift at 1.79 rocker ratio — inlet / exhaust | 0.435 / 0.435 inch |
| Lobe separation angle | 115° |
| Lash specification | Hydraulic / hydraulic |
Supplied contents
| RH inlet | 270XR82 |
|---|---|
| LH inlet | 271XR82 |
| RH exhaust | 272XR82 |
| LH exhaust | 273XR82 |
Four camshafts are supplied. Crow identifies RH as the driver side and LH as the passenger side. Springs, retainers, sprocket hardware and other supporting parts are separate.
Supporting parts and setup
The RH exhaust cam requires ARP 256-1001 to match its thread. Headers, suitable catalytic converters and ECU calibration are required; a vernier gear set may also be needed.
Crow lists standard valve springs for this profile and recommends VTKBAXR8-32 as a spring-and-retainer kit option for 260 kW engines built up to May 2008. Have BBT check the existing springs before choosing the kit.
Contact BBT for the listed companion parts and the correct timing hardware for your engine.
Installation and BBT support
Have the installer verify cam timing, piston-to-valve clearance, spring pressures, coil-bind clearance and retainer-to-seal clearance on the actual engine. BBT can help select the supporting parts and arrange installation and calibration.
