PPM Ford Barra XR6T Forged Piston Kit
PPM Ford Barra XR6T Forged Piston Kit
PPM Ford Barra XR6T Forged Piston Kit
PPM Racing Australia Ford Barra XR6T Forged 2000+hp Pistons
PPM Racing Australia Pistons Feature:
Bore Size: 92.50mm +.010″…
Compression Ratio Dished: 8.5:1 or Flat Top: 9.5:1 Available….
- NPR Japan Nitrated High Performance Rings: 1mm/1.2mm/2.8mm ..
- 4 Valve Pockets..
- Offset Pin which helps reduce piston slap and wear by distributing forces more evenly during operation; this is a common feature in high-performance engines to minimize friction and noise under high loads..
- Double pin oiling which is essential to keep the wrist pin well lubricated..
- Anti-detonation grooves … Anti detonation grooves reduce piston to wall contact under high load and also protect the top ring by disrupting the detonation waves…
- Accumulator grooves accumulate residual gasses from combustion which alleviate top ring flutter and premature second ring wear, improving ring seal…
- A full skirt design to fully reinforce and enhance the strength and rigidity of the piston under high load…
- H/D 9310 0.276” wall DLC Coated Steel Pins …
- Ceramic Thermal Coated Crown and Ring Grooves…
- Phosphate Coating and Moly Skirt Coating…
- Horizontal Gas Ports…
- Locks…
- Forged from Billet 2618 Aluminium…
All of PPM Racing Australia Pistons have been forged from 2618 billet bar stock and have been heat treated and aged to a T61 condition (2618-T61). 2618-T61 is the material that is used when fatigue resistance and durability are of prime importance by all premium racing piston manufacturers worldwide.
Built by Boost & Tune — authorised PPM Racing dealer, reseller and engine builder. BBT can consult on component selection around power target, RPM, fuel, boost, vehicle use and the complete engine combination.
